SL2510, Adjustable Boring Bar Sleeve

SL2510, Adjustable Boring Bar Sleeve

SKU:
TPC89182
$202.39
(No reviews yet)
Width:
1.38 (in)
Height:
1.14 (in)
Depth:
5.91 (in)
Current Stock:
Adding to cart… The item has been added
Description
SL2510 Adjustable Boring Bar Sleeve with a 0.6250" Shank Diameter and a 0.1560" Bar Hole Diameter
Additional Information
Tool Style:
SL
Material:
Steel
Application:
Boring
[DCB] Connection Bore Diameter (mm):
3.96
[H] Shank Height (mm):
7.42
[DCON] Connection Diameter (mm):
15.88
Insert Holding Method:
n/a
Unit (inch/mm):
inch
Feature 1:
Rigid Design
Feature 2:
Adjustable Bar Overhang Length
Feature 3:
For Boring Applications
ANSI Part Number:
SL2510
ISO Part Number:
SL2510
US Stock:
0
Worldwide Stock:
0
Old Material Number:
8604285
Clamp Screw:
SLS-1
Wrench (for Clamp Screw):
LW-2
Shank Type:
Flange Shank
[LF] Functional Length (mm):
101.60
[DCB] Connection Bore Diameter (Decimal Inch):
0.1559
[H] Shank Height (Decimal Inch):
0.2921
[DCON] Connection Diameter (Decimal Inch):
0.6252
[LF] Functional Length (Decimal Inch):
4.0000
