SNG 433 TN620 Grade Uncoated Cermet, Indexable Turning Insert
$16.68
(No reviews yet)
Write a Review
SNG 433 TN620 Grade Uncoated Cermet, Indexable Turning Insert
SNG 433 TN620 Grade Uncoated Cermet, 0 Degree, Square, Negative Rake Angle, Neutral Turning Insert for Light Interruption and Medium-Roughing in (P) Carbon/Alloy Steel
- Tool Style:
- SNG
- Insert Size:
- 433
- Insert Grade:
- TN620
- Material:
- Cermet
- Coating Process:
- Uncoated
- [IC] Inscribed Circle (mm):
- 12.70
- [S] Thickness (mm):
- 4.76
- [RE] Corner Radius (mm):
- 1.20
- Application:
- Boring|Chamfering|External Turning|Facing
- Hand:
- Neutral
- Rake:
- Negative
- [EPSR] Insert Included Angle (Degree):
- 90
- Primary Workpiece Material:
- (P) Carbon/Alloy Steel
- Insert Shape:
- 90 Degree Square
- Number of Cutting Edges:
- 8
- Usage Classification:
- Light Interruption
- Cutting Range:
- Medium-Roughing
- Insert Holding Method:
- Clamp
- Feature 1:
- Insert for External Turning, Facing, Chamfering, Boring
- Feature 2:
- 8 Cutting Edges
- Feature 3:
- Inner structure has high toughness and chipping resistance along with thermal shock resistance
- Feature 4:
- Application: Recommended cermet for stable steel machining and high quality surface finish
- ANSI Part Number:
- SNG433TN620
- ISO Part Number:
- SNG433
- US Stock:
- 20
- Worldwide Stock:
- 0
- Old Material Number:
- 8864115
- Compatible Toolholder (Partial):
- Please Refer to Catalog for Compatible Toolholders
- [IC] Inscribed Circle:
- 1/2"
- [S] Thickness:
- 3/16"
- [RE] Corner Radius:
- 3/64"
