SNM 433T00825 A65 Grade Uncoated Ceramic, Indexable Turning Insert
$26.00
(No reviews yet)
Write a Review
SNM 433T00825 A65 Grade Uncoated Ceramic, Indexable Turning Insert
SNM 433T00825 A65 Grade Uncoated Ceramic, 0 Degree, Square, Negative Rake Angle, Neutral Turning Insert for Continuous and Finishing-Medium in (K) Gray Cast Iron, (H) Hardened Materials
- Tool Style:
- SNM
- Insert Size:
- 433
- Insert Grade:
- A65
- Material:
- Ceramic
- Coating Process:
- Uncoated
- [IC] Inscribed Circle (mm):
- 12.70
- [S] Thickness (mm):
- 4.76
- [RE] Corner Radius (mm):
- 1.20
- Application:
- Boring|Chamfering|External Turning|Facing
- Hand:
- Neutral
- Rake:
- Negative
- [EPSR] Insert Included Angle (Degree):
- 90
- Primary Workpiece Material:
- (K) Gray Cast Iron|(H) Hardened Materials
- Insert Shape:
- 90 Degree Square
- Number of Cutting Edges:
- 8
- Usage Classification:
- Continuous
- Cutting Range:
- Finishing-Medium
- Insert Holding Method:
- Clamp
- Feature 1:
- Insert for External Turning, Facing, Chamfering, Boring
- Feature 2:
- 8 Cutting Edges
- Feature 3:
- Aluminum oxide and titanium carbide ceramic (Al2O3+TiC)
- Feature 4:
- Application: Semi-roughing to finishing of steel, cast iron, and hard materials
- ANSI Part Number:
- SNM433T00825A65
- ISO Part Number:
- SNMN120412T02025
- Old Material Number:
- 8807021
- Compatible Toolholder (Partial):
- Please Refer to Catalog for Compatible Toolholders
- [IC] Inscribed Circle:
- 1/2"
- [S] Thickness:
- 3/16"
- [RE] Corner Radius:
- 3/64"
