SPMR 42EDERH PR1825 Grade PVD Carbide, Indexable Milling Insert
$20.40
(No reviews yet)
Write a Review
SPMR 42EDERH PR1825 Grade PVD Carbide, Indexable Milling Insert
SPMR 42EDERH PR1825 Grade PVD Carbide, 90 Degree Square, Positive Rake Angle, Right-Hand Milling Insert for Roughing in (P) Carbon/Alloy Steel, (P) Mold Steel and (M) Austenitic Stainless Steel
- Tool Style:
- SPMR
- Insert Size:
- 42
- Chipbreaker:
- EDER-H
- Insert Grade:
- PR1825
- Material:
- Carbide
- Coating Process:
- PVD
- [IC] Inscribed Circle:
- 1/2"
- [IC] Inscribed Circle (mm):
- 12.70
- [S] Thickness:
- 1/8"
- [S] Thickness (mm):
- 3.18
- [RE] Corner Radius:
- 0.039"
- [RE] Corner Radius (mm):
- 1.00
- Application:
- Chamfering|Facing
- Hand:
- Right-Hand
- Rake:
- Positive
- [EPSR] Insert Included Angle (Degree):
- 90
- Primary Workpiece Material:
- (P) Carbon/Alloy Steel|(P) Mold Steel
- Insert Shape:
- 90 Degree Square
- Number of Cutting Edges:
- 4
- Cutting Range:
- Roughing
- Insert Holding Method:
- Clamp
- Feature 1:
- MSP Milling Insert for Chamfering, Facing
- Feature 2:
- Honed Edge with 4 Cutting Edges
- Feature 3:
- Longer tool life with next-generation MEGACOAT NANO EX coating technology designed for milling
- Feature 4:
- Multi-layer structure with two unique nano layers for superior abrasion resistance and fracture resistance
- Feature 5:
- Excellent wear resistance oriented grade for steel milling applications
- ANSI Part Number:
- SPMR42EDERHPR1825
- ISO Part Number:
- SPMR1203EDER-H
