SRCPR2525B16A32 Right-Hand, Positive Rake, Square Shank Boring Bar for Bearing Machining

SRCPR2525B16A32 Right-Hand, Positive Rake, Square Shank Boring Bar for Bearing Machining

SKU:
THC01068
|
UPC:
4960664223176
$255.61
(No reviews yet)
Width:
1.97 (in)
Height:
1.73 (in)
Depth:
7.13 (in)
Current Stock:
Adding to cart… The item has been added
Description
SRCPR2525B16A32 Right-Hand, Positive Rake, Square Shank Boring Bar for Bearing Machining with a 32.00mm Minimum Bore Diameter and a 25.00mm Square Shank
Additional Information
Tool Style:
SRCP…B
Material:
Steel
Application:
Bearing Machining|Boring
Hand:
Right-Hand
Rake:
Positive
[KAPR] Tool Entering Angle (Degree):
n/a
Insert Shape:
Round
[DMIN] Minimum Bore Diameter (mm):
32.00
[H] Shank Height (mm):
25.00
[B] Shank Width (mm):
25.00
Insert Holding Method:
Screw
Unit (inch/mm):
mm
Feature 1:
Great for Bearing Machining
Feature 2:
Metric Size
Feature 3:
Compatible with RPMT1604M0-BB inserts
ANSI Part Number:
SRCPR2525B16A32
ISO Part Number:
SRCPR2525B-16-A32
US Stock:
0
Worldwide Stock:
2
Compatible Inserts (Partial):
RPMT1604M0-BB
Old Material Number:
8813858
Insert Screw:
SB-5090TR
Wrench (for Insert Screw):
LTW-20
[LF] Functional Length (mm):
150.00
[LH] Head Length (mm):
31.00
[DMIN] Minimum Bore Diameter (Decimal Inch):
1.2598
[H] Shank Height (Decimal Inch):
0.9843
[B] Shank Width (Decimal Inch):
0.9843
[LF] Functional Length (Decimal Inch):
5.9055
[LH] Head Length (Decimal Inch):
1.2205
Series Description (PeopleSoft):
CBSN Square Shank Boring Bar
Series Description:
CBSN Square Shank Boring Bar
