SS18DRA170M15, DRA Magic Drill 17.00-17.99mm Cutting Diameter, 1.5xD, Replaceable Tip Drill
$300.25
(No reviews yet)
Write a Review
SS18DRA170M15, DRA Magic Drill 17.00-17.99mm Cutting Diameter, 1.5xD, Replaceable Tip Drill
SS18DRA170M15, DRA Magic Drill 17.00-17.99mm Cutting Diameter, 18.00mm Diameter Straight Shank, Coolant-Through Replaceable Tip Drill
- Tool Style:
- SS…DRA
- Material:
- Steel
- Application:
- Drilling
- Hand:
- Right-Hand
- [DCN] Cutting Diameter Minimum (mm):
- 17.00
- [DCX] Cutting Diameter Maximum (mm):
- 17.99
- Drill Depth by Diameter Ratio:
- 1.5xD
- [LU] Usable Length (mm):
- 27.00
- Number of Inserts:
- 1
- Number of Flutes:
- 2
- Shank Type:
- Straight Shank
- Weldon Flat:
- No
- [DCON] Connection Diameter (mm):
- 18.00
- Coolant Through (Yes/No):
- Yes
- Insert Holding Method:
- Screw
- Unit (inch/mm):
- mm
- Feature 1:
- Low Cutting Force Design Improves Hole Accuracy
- Feature 2:
- Optimal Web Thickness Limits Deflection
- Feature 3:
- Fine Chip Breaking Even in Deep Hole Drilling Applications
- Feature 4:
- Easy Insert Replacement
- Feature 5:
- Long Tool Life and Stable Machining of Various Workpieces
- ANSI Part Number:
- SS18DRA170M15
- ISO Part Number:
- SS18-DRA170M-1.5
- Compatible Inserts (Partial):
- DA1700M-…~DA1790M-…
- Old Material Number:
- 8608364
- Clamp Screw:
- HS-3048TRP
- Wrench (for Clamp Screw):
- DTP-6
- Tightening Torque:
- 0.8 Nm (7.1 in/lb)
- [DC] Cutting Diameter (Decimal Inch):
- 0.6693 - 0.7083
- [DC] Cutting Diameter (mm):
- 17.00 - 17.99
- [DCN] Cutting Diameter Minimum (Decimal Inch):
- 0.6693
- [DCX] Cutting Diameter Maximum (Decimal Inch):
- 0.7083
- [LU] Usable Length (Decimal Inch):
- 1.0630
- [DCON] Connection Diameter (Decimal Inch):
- 0.7087
- [LS] Shank Length (mm):
- 48.00
- [LS] Shank Length (Decimal Inch):
- 1.8898
- [OAL] Overall Length (mm):
- 101.00
- [OAL] Overall Length (Decimal Inch):
- 3.9764
