T63H PCMNN H12 Quick Change HSK, Indexable Turning Toolholder
$240.45
(No reviews yet)
Write a Review
T63H PCMNN H12 Quick Change HSK, Indexable Turning Toolholder
T63H PCMNN NH12 Quick Change HSK, Neutral, Negative Rake, Indexable Turning Holder for External Turning, Facing
- Tool Style:
- PCMN
- Material:
- Steel
- Application:
- External Turning|Facing
- Hand:
- Neutral
- Rake:
- Negative
- [KAPR] Tool Entering Angle (Degree):
- 50
- Insert Shape:
- 80 Degree Diamond
- Coolant Through (Yes/No):
- Yes
- Insert Holding Method:
- Lever Lock / Lock Pin
- Unit (inch/mm):
- mm
- Feature 1:
- Compatible with HSK-A type for machining centers
- Feature 2:
- Machining precision for turning is improved by minimizing the gap between the drive key slot on the toolholder side and the drive key on the toolpost side
- Feature 3:
- Compatible with CNMG43…, CNMA43…, CNMM43…, CNGA43…, CNGG43…, CNGM43… inserts
- ANSI Part Number:
- T63HPCMNNH12
- ISO Part Number:
- T63H-PCMNN-H12
- US Stock:
- 0
- Worldwide Stock:
- 3
- Compatible Inserts (Partial):
- CNMG43…, CNMA43…, CNMM43…, CNGA43…, CNGG43…, CNGM43…
- Old Material Number:
- 8832951
- Shim:
- LC-42N
- Shim Pin:
- LSP-2
- Punch:
- PC-2
- Lever:
- LL-2N
- Lock Screw:
- LS-2N
- Coolant Pipe:
- CL63-1
- Wrench (for Lock Screw):
- LW-3
