TKF 16L200S PDL025 Grade DLC Carbide, Indexable Cut-Off Insert
$63.59
(No reviews yet)
Write a Review
TKF 16L200S PDL025 Grade DLC Carbide, Indexable Cut-Off Insert
TKF 16L200S PDL025 Grade DLC Carbide, 2.00mm Cutting Width, Left-Hand Cut-Off Insert for Light Interruption and Finishing-Medium in (N) Non-Ferrous Metals
- Tool Style:
- TKF
- Insert Size:
- 16
- Chipbreaker:
- S
- Insert Grade:
- PDL025
- Material:
- Carbide
- Coating Process:
- DLC
- [S] Thickness (mm):
- 9.50
- [RE] Corner Radius (mm):
- 0.05
- Application:
- Cut-Off|Small Parts Machining
- Hand:
- Left-Hand
- Rake:
- Positive
- [CDX] Max Depth of Cut (mm):
- 8.00
- [CWN] Cutting Width Minimum (mm):
- 2.00
- [CWX] Cutting Width Maximum (mm):
- 2.00
- Primary Workpiece Material:
- (N) Non-Ferrous Materials
- Full Radius:
- No
- Number of Cutting Edges:
- 2
- Usage Classification:
- Light Interruption
- Cutting Range:
- Finishing-Medium
- Insert Holding Method:
- Screw
- Unit (inch/mm):
- mm
- Feature 1:
- Insert for Cut-Off for Small Parts Machining
- Feature 2:
- 2 Cutting Edges
- Feature 3:
- High Hardness with Kyocera’s Proprietary Hydrogen-free DLC Coating
- Feature 4:
- Application: Excellent machining stability in interrupted aluminum machining
- ANSI Part Number:
- TKF16L200SPDL025
- ISO Part Number:
- TKF16L200-S
- Old Material Number:
- 8845326
- Compatible Toolholder (Partial):
- KTKFL...-16JX, KTKFL...JX-16, KTKFL...F-16
- [S] Thickness:
- 0.374"
- [RE] Corner Radius:
- 0.002"
- [CW] Cutting Width (Decimal Inch):
- 0.0787
- [CW] Cutting Width (mm):
- 2.00
- [CDX] Max Depth of Cut (Decimal Inch):
- 0.3150
- [CWN] Cutting Width Minimum (Decimal Inch):
- 0.0787
- [CWX] Cutting Width Maximum (Decimal Inch):
- 0.0787
- Series Description (PeopleSoft):
- KTKF-Series
- Series Description:
- KTKF-Series
