TKN 2P TN620 Grade Uncoated Cermet, Indexable Cut-Off Insert
$17.63
(No reviews yet)
Write a Review
TKN 2P TN620 Grade Uncoated Cermet, Indexable Cut-Off Insert
TKN 2P TN620 Grade Uncoated Cermet, 2.20mm Cutting Width, Neutral Cut-Off Insert for Continuous and Finishing-Medium in (P) Steel
- Tool Style:
- TKN
- Insert Size:
- 2
- Chipbreaker:
- P
- Insert Grade:
- TN620
- Material:
- Cermet
- Coating Process:
- Uncoated
- [RE] Corner Radius (mm):
- 0.20
- Application:
- Cut-Off
- Hand:
- Neutral
- Rake:
- Positive
- [CWN] Cutting Width Minimum (mm):
- 2.20
- [CWX] Cutting Width Maximum (mm):
- 2.20
- Primary Workpiece Material:
- (P) Steel
- Full Radius:
- No
- Number of Cutting Edges:
- 1
- Usage Classification:
- Continuous
- Cutting Range:
- Finishing-Medium
- Insert Holding Method:
- Self-Clamp
- Unit (inch/mm):
- mm
- Feature 1:
- Insert for Cut-Off
- Feature 2:
- Low Feed
- Feature 3:
- 1 Cutting Edge
- Feature 4:
- Inner structure has high toughness and chipping resistance along with thermal shock resistance
- Feature 5:
- Application: Recommended cermet for stable steel machining and high quality surface finish
- ANSI Part Number:
- TKN2PTN620
- ISO Part Number:
- TKN2-P
- Old Material Number:
- 8844935
- Compatible Toolholder (Partial):
- KTKB...-2S
- [RE] Corner Radius:
- 0.008"
- [CW] Cutting Width (Decimal Inch):
- 0.0866
- [CW] Cutting Width (mm):
- 2.20
- [CWN] Cutting Width Minimum (Decimal Inch):
- 0.0866
- [CWX] Cutting Width Maximum (Decimal Inch):
- 0.0866
