TPGB 221T00315ME KBN475 Grade CBN, Indexable Turning Insert

TPGB 221T00315ME KBN475 Grade CBN, Indexable Turning Insert

SKU:
TFB04942
$93.66
(No reviews yet)
Width:
1.69 (in)
Height:
0.43 (in)
Depth:
2.36 (in)
Current Stock:
Adding to cart… The item has been added
Description
TPGB 221T00315ME KBN475 Grade CBN, 11 Degree, Triangle, Positive Rake Angle, Neutral Turning Insert for Continuous and Finishing in (K) Nodular Cast Iron
Additional Information
Tool Style:
TPGB
Insert Size:
221
Insert Grade:
KBN475
Material:
CBN
Coating Process:
Uncoated
[IC] Inscribed Circle (mm):
6.35
[S] Thickness (mm):
3.18
[RE] Corner Radius (mm):
0.40
Application:
Back Boring|Boring|Copying|External Turning|Internal Facing
Hand:
Neutral
Rake:
Positive
[EPSR] Insert Included Angle (Degree):
60
Primary Workpiece Material:
(K) Nodular Cast Iron
Insert Shape:
60 Degree Triangle
Number of Cutting Edges:
3
Usage Classification:
Continuous
Cutting Range:
Finishing
Insert Holding Method:
Screw or Clamp
Feature 1:
Insert for External Turning, Boring, Internal Facing, Copying, Back Boring
Feature 2:
Multi-Edge with 3 Cutting Edges
Feature 3:
Excellent wear resistance due to high CBN content and special binder
Feature 4:
Application: High speed machining of gray cast iron
ANSI Part Number:
TPGB221T00315MEKBN475
ISO Part Number:
TPGB110304T00815ME
Old Material Number:
8844336
Compatible Toolholder (Partial):
STGPR..-11, STGPL..-11, ...-STLPR2..., ...-STLPL2..., ...-STLPR11-..., ...-STLPL11-..., ...-STUPR2, ...-STUPL2, ...-STWPR11-…, ...-STWPL11-…
[IC] Inscribed Circle:
1/4"
[S] Thickness:
1/8"
[RE] Corner Radius:
1/64"
[LE] CBN/PCD Tip Length (Decimal Inch):
0.0827
[LE] CBN/PCD Tip Length (mm):
2.10
